Dell PowerEdge R750xs Server (PER750XS2A)

Dell PowerEdge R750xs Server (PER750XS2A)

The Dell EMC PowerEdge R750xs, with 3rd generation Intel® Xeon® Scalable processors, is purposefully designed with distinctive, customer-defined requirements to deliver enterprise performance for scale-out environments

The Dell EMC OpenManage systems management portfolio tames the complexity of managing and securing IT infrastructure. Using Dell Technologies’ intuitive end-to-end tools, IT can deliver a secure, integrated experience by reducing process and information silos in order to focus on growing the business. The Dell EMC OpenManage portfolio is the key to your innovation engine, unlocking the tools and automation that help you scale, manage, and protect your technology environment.

Order now at Deus.com.gh and have it delivered right at your doorstep.

Remarks/ Condition: New in box

SPECS

Processor Up to two 3rd Generation Intel Xeon Scalable processors with up to 32 cores

Memory: 16 DDR4 DIMM slots, supports RDIMM 1 TB max, speeds up to 3200 MT/s | Supports registered ECC DDR4 DIMMs only

Storage controllers:  Internal controllers: PERC H345, PERC H355, PERC H745, PERC H755, PERC H755N, HBA355i, S150 | Internal Boot: Internal Dual SD Module, Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs, USB | External PERC (RAID): PERC H840, HBA355e.

Drive Bays Front bays:
• 0 drive bay
• Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 128 TB
• Up to 12 x 3.5-inch SAS/SATA (HDD/SSD) max 192 TB
• Up to 8 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 61.44 TB
• Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) max 122.88 TB
• Up to 16 x 2.5-inch (SAS/SATA) + 8 x 2.5-inch (NVMe) (HDD/SSD) max 184.32 TB
Rear bays:
• Up to 2 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) max 15.36 TB

Cooling options: Air cooling

Fans: Standard fans/High performance Silver fans/High performance Gold fans |
Up to six hot swap fans

Dimensions: Height – 86.8 mm (3.41 inches) | Width – 482.0 mm (18.97 inches)
| Depth – 707.78 mm (27.85 inches) – without bezel 721.62 mm (28.4 inches) – with bezel

Form Factor: 2U rack server

Embedded Management:
• iDRAC9
• iDRAC Service Module
• iDRAC Direct
• Quick Sync 2 wireless module

Integrations and Connections
• BMC Truesight
• Microsoft System Center
• OpenManage Integrations
• Red Hat Ansible Modules
• VMware vCenter and vRealize Operations Manager
• IBM Tivoli Netcool/OMNIbus
• IBM Tivoli Network Manager IP Edition
• Micro Focus Operations Manager
• OpenManage Connections
• Nagios Core
• Nagios XI

Security
• Cryptographically signed firmware
• Secure Boot
• Secure Erase
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Embedded NIC 2 x 1 GbE LOM
Network Options 1 x OCP 3.0
GPU Options Not supported
Ports Front Ports
• 1 x iDRAC Direct (Micro-AB USB) port
• 1 x USB 2.0
• 1 x VGA
Rear Ports
• 1 x USB 2.0
• 1 x Serial (optional)
• 1 x USB 3.0
• 2 x Ethernet
• 1 x VGA
Internal Ports
• 1 x USB 3.0 (optional)
PCIe Up to 5 x PCIe Gen4 slots + 1 x PCIe Gen3 slots
• 3 x16 Gen4 low profile
• 2 x16 Gen4 low profile (optional)
• 1 x8 Gen3 (x4 lane) low profile
