Canon imageRUNNER 2930i Photocopier With Inbuilt ADF + PEDESTAL S3 + FINISHER L1 + TONER CEXV 67

Main Unit

• Machine Type

  A3 Monochrome Laser Multifunctional

• Core Functions

  Print, Copy, Scan, Send and Optional Fax

• Processor Speed

  1.6GHz Dual Core Processor

• Control Panel

  Standard: 7 inch TFT LCD WVGA Colour Touch panel

• Memory

  Standard: 2.0GB RAM

• Storage

  Standard: 64GB eMMC
  Optional: 256GB SSD

• Interface Connection

  NETWORK Standard:
  1000Base-T/100Base-TX/10-Base-T, Wireless LAN (IEEE 802.11 b/g/n), Wi-Fi Direct Connection
  OTHERS Standard:
  USB 2.0 (Host) x2, USB 2.0 (Device) x1

• Paper Input (Standard)

  Paper Input (Standard)

• Paper Supply Capacity (A4, 80 gsm)

  Standard: 1,200 sheets
  Maximum: 2,300 sheets (with Cassette Feeding Unit-AW1)

• Paper Output Capacity (A4, 80 gsm)

  Standard: 250 sheets
  Maximum: 645 sheets (with Inner Finisher-L1 and Copy Tray-T2)

• Finishing Capabilities

  Collate, Group, Offset, Staple, Hole Punch, Eco Staple, Staple On Demand¹

• Supported Media Types

  Main Body Cassette (Upper/Lower):
  Thin, Plain, Recycled, Color, Heavy, Bond, Pre-Punched, Letterhead, PostCard

  Multi-purpose Tray:
  Thin, Plain, Recycled, Color, Heavy, Bond, Pre-Punched, Letterhead, PostCard, Labels, Coated, Tracing

• Supported Media Sizes

  Upper Cassette:
  Standard size: A4, A5, A5R, A6R, B5
  Custom Size: 105.0 x 148.0 mm to 297.0 x 215.9 mm

  Lower Cassette:
  Standard size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R, COM 10 No. 10*, Monarch*, DL*

  Custom Size: 105 x 148 mm to 304.8 x 457.2 mm

  *Requires Envelope Attachment A (std)

• Supported Media Weights

  Main Body Cassette (Upper/Lower): 52 to 256 gsm

  Multi-purpose tray: 52 to 300 gsm

  Duplex: 52 to 220 gsm

• Warm-up Time

  4 Seconds or Less

  From Sleep Mode: 10 seconds or less

  From Power On: 10 Seconds or Less

• Dimensions (W x D x H)

  565 x 693 x 852 mm

• Installation Space (W x D)

  1,286 x 1,122 mm (with DADF-AZ2 + Inner Finisher tray max extended + Copy Tray-T2 max extended + paper cassette opened）

• Weight

  Approx. 65 kg

Print Specifications

• Print Speed

  Up to 30 ppm (A4, A5, A5R, A6R), Up to 15 ppm (A3), Up to 20 ppm (A4R)

• Print Resolution (dpi)

  Up to 1200 x 1200

• Page Description Languages

  Standard: UFRII, PCL6,
  Optional: Adobe^® PostScript^®3TM

• Double-Sided Printing

  Yes

• Direct Print

  PDF, EPS, TIFF/JPEG, XPS

• Mobile / Cloud Printing

  AirPrint, Mopria, Canon PRINT Business, uniFLOW Online and Universal Print by Microsoft

• Fonts

  PS fonts: 136 Roman
  PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T1 (Japanese, Korean, Simplified and Traditional Chinese) , Barcode fonts2

• Print Features

  Secure Print, Secure Watermark, Header/Footer, Page Layout, Duplex Printing, Mixed Paper Sizes/ Orientations, Toner Reduction, Poster Printing, Forced hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer

• Operating Systems

  UFRII: Windows^® 10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022, Mac OS X (10.13 or later)
  PCL: Windows^® 10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022
  PS: Windows^® 10/11/Server2012/Server2012 R2/Server2016/Server2019/Server2022, Mac OS X (10.13 or later)
  PPD: Windows^® 10/11, Mac OS X (10.13 or later)

Copy Specifications

• Copy Speed

  Up to 30 ppm (A4, A5, A5R, A6R), Up to 15 ppm (A3), Up to 20 ppm (A4R)

• First-Copy-Out Time

  7 seconds

• Copy Resolution (dpi)

  600 x 600

• Multiple Copies

  up to 999 copies

• Copy Density

  Automatic or Manual (9 Levels)

• Magnification

  25% - 400% (1% Increments)

• Preset Reductions

  25%, 50%, 70%, 100% (1:1), 141%, 200%, 400%

• Preset Enlargements

  25%, 50%, 70%, 100% (1:1), 141%, 200%, 400%

• Basic Copy Features

  Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Sort, Job Build, N on 1, Different Size Originals, Sharpness, Erase Frame, Copy ID Card, Skip Blank Pages, Free Size Original, Color Mode, Reserved copy, Copy Sample

Scan Specifications

• Type

  Color Scanner

• Pull Scan Specifications

  Colour Network ScanGear2. For both TWAIN and WIA Supported OS:
  Windows^® 10/11/Server2012/Server2012 R2/Server 2016/Server 2019/Server202

• Scan Resolution (dpi)

  Scan for Copy: 600 x 600
  Scan for Send: (Push) 600 x 600 (SMB/FTP/WebDAV/IFAX), (Pull) 600 x 600
  Scan for Fax: 600 x 600

• Document Feeder Paper Capacity (80 gsm)

  up to 50 sheets

• Acceptable Originals/Weights

  Platen: Sheet, Book, 3-Dimensional Objects
  Document Feeder sheet media weight:
  1-sided scanning: 38 to 128 gsm (BW/CL)
  2-sided scanning: 52 to 128 gsm (BW/CL)

• Supported Media Sizes

  Platen: max. scanning size: 297.0 x 431.8 mm
  DADF: A3, A4, A4R, A5, A5R, B4, B5, B5R,
  Custom size: 148.0 x 128.0 mm to 297.0 x 431.8 mm

• Scan Method

  Push Scan, Pull Scan, Scan to Network, Scan to USB Memory Key, Scan to Mobile device, Scan to cloud-based services (uniFLOW Online)

• Scan Speed

  1-sided Scanning: 35/25 (300 x 300 dpi, send), 25/- (600 x 600 dpi, copy) 2-sided Scanning: 12/8 (300 x 300 dpi, send), 8/- (600 x 600 dpi, copy)

• Double-Sided Scanning

  Yes

Send Specifications

• Optional / Standard

  Standard

• Destination

  Standard: E-mail/Internet FAX (SMTP), SMB3.0, FTP, WebDAV,
  Optional: Super G3 FAX

• Address Book / Speed Dials

  LDAP (2,000)/ Local (1,600) /Speed dial (200)

• Send Resolution (dpi)

  Push: up to 600 x 600
  Pull: up to 600 x 600

• Communication Protocol

  FTP (TCP/IP), SMB3.0 (TCP/IP), WebDAV
  Email/iFax: SMTP(send), POP3(receive)

• File Format

  Standard: TIFF (MMR), JPEG {foot}, PDF (Compact, Searchable, PDF/A-1b, Encrypted), XPS (Compact, Searchable), PDF/XPS (Device Signature, Office Open XML (PowerPoint, Word)
  Optional: PDF (Trace & Smooth), PDF/XPS (User Signature)

• Universal Send Features

  Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation

Fax Specifications

• Optional / Standard

  Optional

• Maximum Number of Connection Lines

  1

• Modem Speed

  Super G3: 33.6 kbps
  G3： 14.4 kbps

• Compression Method

  MH, MR, MMR, JBIG

• Resolution (dpi)

  200x100dpi (Standard), 200x200dpi (Fine), 200x400 dpi (Super Fine), 400x400 dpi (Ultra Fine)

• Sending/Receiving Size

  Sending: A3, A4, A4R, A5*1, A5R*1, B4, B5*2, B5R*1
  Receiving: A3, A4, A4R, A5R, B4, B5, B5R

  *1 Sent as A4.
  *2 Sent as B4 short.

• FAX Memory

  Up to 30,000 pages (2,000 jobs)

• Speed Dials

  Max. 200

• Group Dials/Destinations

  Max. 199 dials

• Sequential Broadcast

  Max. 256 addresses

• Memory Backup

  Yes

• Fax Features

  Sender's Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Finished Stamp, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Sub-address Sending, Confidential Mailbox

Store Specifications

• Memory Media

  Standard: USB Memory

Security Specifications

• Authentication & Access Control

  User Authentication(Picture Login, Picture and PIN Login, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication(Depertment ID and PIN Login, Function Level Login), uniFLOW Online (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Depertment ID and PIN Login, Function Level Login), Access Management System(Access Control)

• Network Security

  TLS 1.3, IPSec, IEEE802.1X authentication, SNMPv3, Firewall, Functionality(IP/MAC Address Filtering), WPA3 support (Wi-Fi), Dual Network Support(Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Enabling/Disabling(Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Scan and Send -Virus Concerns for E-mail Reception

• Document Security

  Print Security(Secure Print, Encrypted SecurePrint, Forced Hold Printing, uniFLOW Secure Print1), Receive Data Security(Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS2), Send Data Security(Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support)

• Device Security

  Standard Storage Initialize, Job Log Conceal Function, Checking MFP Software Integrity, (Verify System at Startup, Automatic Recovery, Runtime Intrusion Detection)

• Device Management & Auditing

  Administrator Password, Digital Certificate and Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Security Policy Setting, Remote Management Two-factor Authentication

Environmental Specifications

• Operating Environment

  Temperature: 10 to 30 °C (50 to 86 °F)
  Humidity: 20 to 80 % RH (Relative Humidity)

• Power Source

  EUR: 220-240V 50/60Hz 10A

• Power Consumption

  Maximum: Approx. 1,500W
  Copying (with DADF continuous scan): Approx. 666W (220-240V) *1
  Standby: Approx. 28.1W (220-240V) *1
  Sleep Mode: Approx. Wired LAN: 0.8W*2

  *1 Reference value: measured one unit
  *2 0.8W is not available in all circumstances due to certain settings.

  Typical Electricity Consumption (TEC): 0.33 kWh*

  *As per ENERGY STAR Version 3.0

  For detailed information relating to Lot26 regulation, please go to: https://www.canon-europe.com/for_work/lot26/

• Noise Levels

  Sound Power Level (LWA,m)
  Active (BW)(1-sided): 6.4B, Kv 0.3B

  Sound Pressure (LpAm)
  Bystander's position: TBD
  Active(BW/CL)(1-sided): TBD

  *Reference value: measured only one unit with ISO7779, described with ISO9296 (2017)

  *Reference value: measured only one unit with ISO7779, described with ISO9296 (2017)

• Standards

  Blue Angel

Software & Printer Management

• Tracking & Reporting

  uniFLOW Online

• Remote Management Tools

  iW Enterprise Management Console
  eMaintenance
  Content Delivery System

• Scanning Software

  Network ScanGear

• Optimisation Tools

  Canon Driver Configuration Tool

Consumables

• Toner Cartridge/s

  Toner C-EXV 67 Black

• Toner Estimated Yield

  33,000 pages (A4)
  (Estimated @ 6% coverage)

Paper Supply Options

• Cassette Feeding Unit

  Cassette Feeding Unit-AW1:
  Paper Capacity: 550 sheets x 2 (1,100 sheets) (80 gsm)
  Paper Type: Thin, Plain, Recycled, Color, Heavy, Bond, Transparency, Pre-punched, Letterhead
  Paper Size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R,
  Custom Size: 105.0 x 148.0 mm to 304.8 x 457.2 mm
  Paper Weight: 52 to 256 gsm
  Power Source: From the Main Unit
  Dimensions (W x D x H): 565 x 635 x 248 mm
  Weight: Approx. 16.0 kg

Output Options

• Copy Tray

  Check for impacted products.

  Inner 2way Tray-M1:

  Tray Capacity (with 80 gsm paper):
  Upper tray: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R: 100 sheets
  Lower tray (standard tray): A4, A5, A5R, A6R, B5, B5R: up to 250 sheets
  　　　　　　 SRA3, A3, A4R, B4: up to 100 sheets
  Paper Weight: 52 to 300 gsm
  Dimensions (W x D x H): 428 x 405 x 88 mm
  Weight: Approx. 0.7 kg

  Copy Tray-T2:

  Capacity (80gsm paper):
  A4, A5R, B5, B5R: 100 sheets
  A3, A4R, B4: 65 sheets
  Dimensions (W x D x H): 444 × 373 × 176 mm (attached to the main unit, when the extension tray is extended)
  Weight: 0.5 kg

•

• Hole Puncher

  1 product to be migrated.

• Inner 2/4 Hole Puncher

  Inner 2/4 Hole Puncher-D1:

  (Requires Inner Finisher-L1)
  Two or Four Holes
  Acceptable Punch Paper Weight: 52 to 300 gsm
  Acceptable Punch Paper Size:
  Two holes: A3, A4, A4R, A5, B4, B5, B5R,
  Four holes: A3, A4

  Inner 4 Hole Puncher-D1:

  (Requires Inner Finisher-L1)
  Acceptable Punch Paper Weight: 52 to 300 gsm
  Acceptable Punch Paper Size:
  A3, A4, A4R, A5, B4, B5, B5R

Hardware Accessories

• Card Readers

  IC Card Reader Attachment-B4
  Attachment kit for Reader-A2

Security Options

• Data Security

  Picture Login-A1

System & Controller Options

• Print Accessories

  PCL International Font Set-A
  PS Printer Kit-BT1

• Send Options

  Universal Send Trace & Smooth PDF Kit-A1
  Universal Send Digital User Signature Kit-C1

• Barcode Printing

  Barcode Printing Kit-D1

• System Accessories

  Copy Control Interface Kit-D1

• Fax Accessories

  Super G3 FAX BD-BN1 EU
  Remote Fax Kit-A1

Other Options

• Staple Cartridge

  Staple-P1

• Accessibility Accessories

  ADF Access Handle-A1
